V2000 ACCURACY

dynamic checkweigher

The V2000 Accuracy checkweigher offers the maximum accuracy in checkweighing and the highest performance within strict production tolerances. This equipment helps to control the quality and profitability of high productions in the pharmaceutical or cosmetic industries. There is the option of hygienic approach in its design to meet the needs of the market in terms of cleanliness and accessibility.

The V2000 Accuracy is equipped with the latest advances in technology: touch screen, extensive communications systems, advanced weighing electronics, maximum precision and state-of-the-art software.

The V2000 Accuracy offers a robust and stable structure that requires little installation space. Its modular system with height adjustment provides flexibility and makes easier the installation and commissioning of the equipment.

Technical features
Production
Up to 300 p/min.
Accuracy
From 0,1 g* (6 g metrology)
Division unit
From 0,01 g
Memory formats
Up to 900
Screen
LCD-LED color touch screen 12”
Protection
IP65 / IP66 (optional)
Maximum weight to control
Up to 1 kg
Minimum weight to control
From 1 g* (6 g metrology)
Motor Servo Motor
Working temperature
0-40ºC
Working height
600-1200 mm
Included elements
ADJUSTMENT
Static and dynamic adjustment of products
CONTROL
Full control of all processed products
SELF-LEARNING
Product self-learning to optimize production
AUTOZERO
Autozero - Autotrack for automatic weight adjustment
AUDIT
Audit-trail of settings and configurations
SOFTWARE
Intuitive human-machine interface
DIAGNOSIS
Check of the correct operation of the equipment
USERS
Advanced user control and access with a three-level password
SECURITY
Data integrity
security

REJECTION INFORMATION
Queries, export and analysis of rejections
LANGUAGES
Language
selection

UNITS
Selection of measurement units according to the needs
SPEED
Automatic speed variation
PROTECTION
Weighing zone protection
ANTI-VIBRATION
Anti-vibration reinforcement base
Accessories and complements
GUIDES
Adjustable side guides and upper guides
FEEDERS
Magnetic feeders, sidebands, pass-through, sequencers, screw feeders, etc.
AIR CONDITIONING
Air conditioning for extreme temperatures
ALARMS AND BEACONS
Light and / or acoustic beacon and alarms
REJECTION DEVICES
Pushers, blowers, turnouts, tilting, progressive, retractable, etc.
COLLECTION
Rejected product collection system
IP
Degree of protection suitable for harsh environments
SENSORS
Sensors adapted to the product
ADAPTATION
Possibility of different measures in working height, weight zone, conveyors and rejection
PROTECTIONS
Fairings against drafts, accesses, etc.
DOUBLE WEIGHING
Possibility of a double weighing station
HYGIENIC DESIGN
Hygienic design based on EHEDG concepts
INCLINED PLANE
Design adapted to inclined lines
ANTI-VIBRATION
Anti-vibration reinforcement base
BENCH
Independent
bench

SCREEN
Articulated arm screen
PRINTER
Integrated data printer
UPS
Uninterruptible power supply
Additional elements: communications, controls and technologies
DIGITAL SIGNALS
Management of digital signals for communication with the line
USB
USB connection port
PROTOCOLS
Communication protocols DATAHUB WEB, MODBUS TCP IP, OPC UA, etc.
CONNECTIONS
Ethernet connections
READER
Manual or automatic barcode, QR and IR reader
MAINS VOLTAGE
Electrical voltages adapted to the client at 50/60 Hz
SOFTWARE
Software to improve performance and profitability under request
VIT4
VIT4 software for production data management
REMOTE CONNECTION
Remote communication for remote maintenance and / or technical support
VISION
Possibility of adding inspection by vision to complete product information
PULSES
Pulse speed variation
PRODUCTION CONTROL
Control of downtimes, shifts, partials, weight out
FEEDBACK
Feedback for proportional dosing system, PID or moving average
CONFIRMATION
Confirmation of correct or rejected products (full confirmation), M&S process
ACCUMULATION
Detection system for rejected product accumulation
LIST
Automatic production listing
