V2000 statiC

static checkweighers

The V2000 Static checkweigher meets market demands in terms of precision and accuracy for applications that require product stability control. The product is placed on the equipment for weighing with a static pause. This way the quality of production can be controlled.

The V2000 Static is especially suitable for cylindrical or rectangular containers. It requires little installation space thanks to its compact and stable construction. It includes advanced weighing electronics, maximum precision, and state-of-the-art software, as well as a touch screen and extensive communications systems.

It is a very versatile unit thanks to its modular system, which provides flexibility and facilitates the installation and commissioning of the equipment.

Technical features
Production
Up to 400 p/min.
Accuracy
From 0,1 g* (6 g metrology)
Division unit
From 0,1 g
Memory formats
Up to 900
Screen
LCD-LED color touch screen 12”
Protection
IP65 / IP66 (optional)
Maximum weight to control
Up to 2 kg
Minimum weight to control
From 1 g* (6 g metrology)
Motor Asynchronous and/or Servo Motor
Working temperature
0-40ºC
Working height
600-1200 mm
Included elements
ADJUSTMENT
Static and dynamic adjustment of products
CONTROL
Full control of all processed products
SELF-LEARNING
Product self-learning to optimize production
AUTOZERO
Autozero - Autotrack for automatic weight adjustment
AUDIT
Audit-trail of settings and configurations
SOFTWARE
Intuitive human-machine interface
DIAGNOSIS
Check of the correct operation of the equipment
USERS
Advanced user control and access with a three-level password
SECURITY
Data integrity
security

REJECTION INFORMATION
Queries, export and analysis of rejections
LANGUAGES
Language
selection

UNITS
Selection of measurement units according to the needs
REJECTION DEVICE
Integrated rejection device
BEACON
Light and / or acoustic beacon
BENCH
Independent
bench
ANTI-VIBRATION
Anti-vibration reinforcement base
Accessories and complements
GUIDES
Adjustable side guides and upper guides
SCREEN
Articulated arm screen
AIR CONDITIONING
Air conditioning for extreme temperatures
ALARMS AND BEACONS
Light and / or acoustic beacon and alarms
UPS
Uninterruptible power supply
COLLECTION
Rejected product collection system
IP
Degree of protection suitable for harsh environments
SENSORS
Sensors adapted to the product
ADAPTATION
Possibility of different measures in working height, weight zone, conveyors and rejection
PROTECTIONS
Fairings against drafts, accesses, etc.
DOUBLE WEIGHING
Possibility of a double weighing station
PRINTER
Integrated data printer
Additional elements: communications, controls and technologies
DIGITAL SIGNALS
Management of digital signals for communication with the line
USB
USB connection port
PROTOCOLS
Communication protocols DATAHUB WEB, MODBUS TCP IP, OPC UA, etc.
CONNECTIONS
Ethernet connections
LIST
Automatic production listing
MAINS VOLTAGE
Electrical voltages adapted to the client at 50/60 Hz
SOFTWARE
Software to improve performance and profitability under request
VIT4
VIT4 software for production data management
REMOTE CONNECTION
Remote communication for remote maintenance and / or technical support
READER
Manual or automatic barcode, QR and IR reader
VISION
Possibility of adding inspection by vision to complete product information
PRODUCTION CONTROL
Control of downtimes, shifts, partials, weight out
FEEDBACK
Feedback for proportional dosing system, PID or moving average
CONFIRMATION
Confirmation of correct or rejected products (full confirmation), M&S process
ACCUMULATION
Detection system for rejected product accumulation
