V2000 rotary

rotary checkweighing equipment

The V2000 Rotary checkweigher meets the demands of specific markets such as aerosols. This rotary star operated equipment helps to control production quality and profitability thanks to precise weight control.

The V2000 Rotary offers a robust and stable structure that requires little installation space. It includes advanced weighing electronics, maximum precision, state-of-the-art software and the latest advances in technology: touch screen and extensive communications systems.

This system offers the possibility of a hygienic approach in its design to meet the needs of very specific markets in terms of cleanliness and accessibility.

It is a versatile piece of equipment thanks to its modular system, which provides flexibility and makes easier the installation and start-up of the equipment. The V2000 Rotary is mounted on conveyor belt of the customer (not included).

Technical features
Production
Up to 60 or 120 p/min.
Accuracy
From 0,1 g* (6 g metrology)
Division unit
From 0,1 g
Memory formats
Up to 900
Screen
LCD-LED color touch screen 12”
Protection
IP65 / IP66 (optional)
Maximum weight to control
Up to 1 kg
Minimum weight to control
From 1 g* (6 g metrology)
Motor Asynchronous and/or Servo Motor
Working temperature
0-40ºC
Working height
600-1200 mm
Included elements
ADJUSTMENT
Static and dynamic adjustment of products
CONTROL
Full control of all processed products
SELF-LEARNING
Product self-learning to optimize production
AUTOZERO
Autozero - Autotrack for automatic weight adjustment
AUDIT
Audit-trail of settings and configurations
SOFTWARE
Intuitive human-machine interface
DIAGNOSIS
Check of the correct operation of the equipment
USERS
Advanced user control and access with a three-level password
SECURITY
Data integrity
security

REJECTION INFORMATION
Queries, export and analysis of rejections
LANGUAGES
Language
selection

UNITS
Selection of measurement units according to the needs
ROTARY
Rotary product guides in star format
REJECTION DEVICE
Internal rejection device
ALARMS & BEACONS
Light and / or acoustic beacon and alarms
PROTECTIONS
Fairings against drafts, accesses, etc.
HYGIENIC DESIGN
Hygienic design based on EHEDG concepts
Accessories and complements
GUIDES
Adjustable side guides and upper guides
FEEDERS
Magnetic feeders, sidebands, pass-through, sequencers, screw feeders, etc.
AIR CONDITIONING
Air conditioning for extreme temperatures
PRINTER
Integrated data printer
SCREEN
Articulated arm screen
UPS
Uninterruptible power supply
IP
Degree of protection suitable for harsh environments
PROTECTIONS
Fairings against drafts, accesses, etc
Additional elements: communications, controls and technologies
DIGITAL SIGNALS
Management of digital signals for communication with the line
USB
USB connection port
PROTOCOLS
Communication protocols DATAHUB WEB, MODBUS TCP IP, OPC UA, etc.
CONNECTIONS
Ethernet connections
LIST
Automatic production listing
MAINS VOLTAGE
Electrical voltages adapted to the client at 50/60 Hz
SOFTWARE
Software to improve performance and profitability under request
VIT4
VIT4 software for production data management
REMOTE CONNECTION
Remote communication for remote maintenance and / or technical support
READER
Manual or automatic barcode, QR and IR reader
VISION
Possibility of adding inspection by vision to complete product information
PRODUCTION CONTROL
Control of downtimes, shifts, partials, weight out
FEEDBACK
Feedback for proportional dosing system, PID or moving average
CONFIRMATION
Confirmation of correct or rejected products (full confirmation), M&S process
ACCUMULATION
Detection system for rejected product accumulation
